Warehouses,factories,hangars.
Industrial UFO high-bay luminaire. TYF 3030, > 170 lm/W LED, CRI 80, suspension or bracket mount.
Above the work.
The industrial high-bay is engineered for the floors that operate around the clock — warehouses, factories, hangars, cold storage. The TYF 3030 LED package pulls more than 170 lumens per watt; the integrated driver is rated for 50,000 hours of continuous duty. CRI 80 keeps colour true on inventory pickline and machine-bench. Suspension or wall-bracket mount, 90 – 100° beam angle, IP66 sealed against industrial atmosphere.
The headline figures that put Fusion Pro on tendered municipal projects.
- 29K lm Peak output
- 170 lm/W LED efficacy
- 80 CRI Colour accuracy
- 50K hrs Rated life
The completespecification.
01Electrical
- Rated power
- 70 W · 100 W · 150 W · 200 W
- LED driver type
- Suncom · Philips
- Voltage
- 220 – 240 V · 50 / 60 Hz
- Power factor
- ≥ 0.95 nominal
- Drive current
- 100 mA – 1000 mA
- Surge protection
- SPD 4 kV built-in (10 kV dedicated optional)
02Light
- Total lumens
- >10,150 · >14,500 · >21,750 · >29,000 lm
- Light source
- TYF 3030 · > 170 lm/W
- System efficacy
- Up to 145 lm/W
- CRI
- Minimum 80 (industrial-grade colour accuracy)
- Beam angle
- 90° – 100°
- CCT
- CW 5700K · NW 4000K · WW 3000K ±500K
- Lifetime
- > 50,000 hrs (L70 @ Ta = 35°C)
03Environmental
- Installation
- Suspension or typical flood wall-bracket
- Working temp.
- −40 °C to +55 °C
- Humidity
- Up to 95% RH
04Mechanical
- Housing
- High pressure die-cast aluminium
- Gasket
- Heat-resistant silicone rubber
- Finish
- Corrosion-resistant powder coating
- Certifications
- CE · ROHS · FCC
- Classification
- IP65 / IP66 · IK08
- Maintenance
- Dynamic opening of gear compartment
Above the rafterwhere the work happens.
- LED
- TYF 3030
- Source
- > 170 lm/W
- CRI
- 80
- System
- up to 145 lm/W
- Lifetime
- 50,000 hrs
- Ingress
- IP66 / IK08
Fusion Pro in the field
- 01
Warehouses
Aisle illumination on 12-metre racks.
- 02
Factory floors
Machine shops, paint booths, assembly lines.
- 03
Hangars
Aircraft and equipment storage spans.
- 04
Cold storage
Sealed against condensation, low-temp rated.
70200W
The range of Fusion Pro, by application.
- 0170 W
Workshops, small bays, retail
- 02100 W
Light industrial, distribution centres
- 03150 W
Warehouses, factory floors
- 04200 W
Hangars, large-span industrial halls
